800V DC Miniature Circuit Breaker Carisol-MDB2Z-63 2P600V 10-32A

800V DC Miniature Circuit Breaker Carisol MDB2Z-63 2P800V 10-32A

Overview

The Carisol MDB2Z-63 2P800V 10-32A DC Miniature Circuit Breaker (MCB) is a high-performance protection device specifically designed for photovoltaic (PV) solar systems, battery energy storage systems (ESS), and other direct current (DC) electrical applications. Engineered to provide reliable overload and short-circuit protection, this 2-pole DC circuit breaker safely disconnects electrical circuits during fault conditions, protecting valuable equipment and ensuring uninterrupted system performance. Its compact DIN rail mounting design makes installation quick and convenient for residential, commercial, and industrial electrical installations.

Features

• Rated voltage up to 800V DC.
• Current ratings available from 10A to 32A.
• 2-Pole (2P) configuration for enhanced circuit isolation.
• Thermal-magnetic tripping mechanism for reliable protection.
• Provides overload and short-circuit protection.
• Designed specifically for solar photovoltaic (PV) systems.
• Suitable for battery energy storage systems (ESS).
• Fast DC arc extinguishing technology.
• DIN rail mounting for easy installation.
• Compact and space-saving design.
• High electrical and mechanical durability.
• Flame-retardant, high-strength housing.
• Low maintenance operation.
• Reliable performance in demanding environments.
• Complies with international electrical safety standards.

Benefits

The Carisol MDB2Z-63 DC Miniature Circuit Breaker enhances the safety and reliability of DC electrical systems by providing dependable circuit protection against overloads and short circuits. It minimizes equipment damage, reduces maintenance costs, and improves system uptime, making it an ideal solution for renewable energy installations and industrial DC applications.

• Protects solar panels, batteries, and inverters from electrical faults.
• Improves overall system safety and reliability.
• Helps prevent costly equipment failures.
• Supports long service life with minimal maintenance.
• Ensures quick interruption of fault currents.
• Ideal for residential, commercial, and industrial solar systems.
• Easy installation and replacement on standard DIN rails.
• Reduces downtime during maintenance and repairs.

Advantages

Designed with advanced DC protection technology, the Carisol MDB2Z-63 offers superior performance in high-voltage direct current applications where dependable protection is essential.

• Optimized for 800V DC photovoltaic systems.
• Excellent DC arc suppression capability.
• Stable thermal-magnetic trip characteristics.
• Compact construction saves enclosure space.
• High-quality materials for extended operational life.
• Suitable for harsh indoor electrical environments.
• Wide current range from 10A to 32A.
• Reliable protection for battery storage and solar installations.
• Easy integration into new or existing electrical systems.
• Trusted Carisol quality and performance.

Conclusion

The Carisol MDB2Z-63 2P800V 10-32A DC Miniature Circuit Breaker is a dependable and efficient protection device for modern solar photovoltaic systems, battery storage installations, and DC power distribution networks. With advanced overload and short-circuit protection, durable construction, and simple DIN rail installation, it provides long-lasting performance and peace of mind. Whether for residential, commercial, or industrial applications, this circuit breaker is an excellent investment for ensuring safe, reliable, and efficient DC electrical protection.
